Sony BRAVIA 4K HDR LCD Pro Display with Pro-Mode, Airplay, and Chromecast

Discover the Sony BZ30L series, a range of high-performance professional displays designed to meet the needs of various commercial and professional environments. With sizes ranging from 43 inches to an impressive 98 inches, these displays offer stunning 4K resolution, ensuring crystal-clear visuals and vibrant color reproduction. The BZ30L series is engineered for versatility, making it ideal for everything from corporate meeting rooms and educational institutions to retail and control rooms.

Each model in the BZ30L series shares core features that make them stand out. They come equipped with 4K Ultra HD resolution, providing sharp and detailed images that are crucial for presentations, video playback, and data visualization. The displays feature advanced connectivity options including HDMI and DisplayPort, along with integrated speakers for a complete multimedia experience. Additionally, they support both landscape and portrait orientations, offering flexibility in installation to suit various application needs.

While the core features remain consistent across the series, the models differ in size to cater to different display requirements. From the compact 43-inch model, ideal for smaller spaces or focused viewing areas, to the expansive 98-inch display for large venues or high-impact presentations, each variant offers the same high-quality performance in a size that best fits your specific use case. Whether you need a display for a small conference room or a large auditorium, the BZ30L series provides the perfect solution.

Key Features

• 4K Ultra HD Resolution for sharp and detailed visuals
• Advanced connectivity options including HDMI and DisplayPort
• Integrated speakers for a complete multimedia experience
• Supports both landscape and portrait orientations
• Suitable for various commercial and professional environments

Technical Specifications

55” Model

General Features
Screen Size
55“
Brightness (cd/m²)
440
Contrast Ratio
5000:1
Dynamic Contrast Ratio
300,000:1
Response Time (ms)
9.5
Display Resolution (H x V, pixels)
3840 x 2160
HDR (High Dynamic Range) Compatibility
Yes (HDR10, HLG, Dolby Vision)
Aspect Ratio
16:9
Portrait/Tilt Compatibility
Yes

Display Features
Dimming Type
Frame Dimming
Display Device
LCD
Panel Type
VA
Backlight Type
Direct LED
TRILUMINOS Display
TRILUMINOS PRO
Color Gamut (DCI-P3)
92%
Picture Processor
4K HDR Processor X1
Operation Time
24/7
Deep Black Non-Glare Coating
No
Haze (%)
1%
Viewing Angle (Right/Left)
178(89/89) degrees
Viewing Angle (Up/Down)
178(89/89) degrees

Video Specs
Video Processing
4K X-Reality PRO
Motion Enhancer
Motionflow XR 240 (Native 60Hz)
HDMI Signal
4096 x 2160 p (24, 60 Hz), 3840 x 2160 p (24, 30, 60 Hz), 1080 p (24, 30, 60 Hz), 1080 i (60 Hz), 720 p (24, 30, 60 Hz), 480 p

Audio Specs
Speaker Position
Down Firing
Audio Power Output
10W + 10W

Professional Features
Pro Mode
Yes
HDMI Auto Wake-Up
Yes
HTML5 Platform
Yes
Multicast/IPTV
Yes
Operating System
Android TV
On-board Storage (GB)
16GB

Network Specs
Wi-Fi Direct
Yes
Wi-Fi Certified
Yes
Wireless LAN
Integrated

Convenience Features
USB Playback Codecs
MPEG1: MPEG1 / MPEG2PS: MPEG2 / MPEG2TS (HDV, AVCHD): MPEG2, AVC / MP4 (XAVCS): AVC, MPEG4, HEVC / AVI: Xvid, MotionJpeg / ASF (WMV): VC1 / MOV: AVC, MPEG4, MotionJpeg / MKV: Xvid, AVC, MPEG4, VP8.HEVC / WEBM: VP8 / 3GPP: MPEG4, AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG
On Screen Clock
Yes
Sleep Timer
Yes
On/Off Timer
Yes
Chromecast Built-in
Yes
Apple AirPlay
Yes

Control Specs
IP Control
Yes
RS-232C Control
Yes
HDMI-CEC
Yes

Inputs and Outputs
HDCP
HDCP2.3 (for HDMI 1/2/3/4)
Composite Video Input(s)
1 (Side, Mini jack)
HDMI Inputs Total
4 (4 Side)
Analog Audio Input(s) (Total)
1 (Side Analog Conversion)
Digital Audio Output(s)
1 (Side)
USB Ports
2 (Side)
Ethernet Inputs
1 (Side)

Design Features
VESA® Hole Pitch (W x H)
300 x 300 mm / 11.8 x 11.8 inch

Accessories
Wall-Mount Adjuster (Bundled)
*depending on the region.
Table-Top Stand (Optional)
*depending on the region.

Environment Specs
Rated Power Consumption
127 W
Power Consumption (in Standby)
0.5 W
Dynamic Backlight Control
Yes
Power Saving Mode / Back Light Off Mode
Yes

Measurements
Dimension of TV Without Stand (W x H x D)
1,232 x 708 x 70 mm / 48 5/8 x 27 7/8 x 2 7/8 inch
Dimension of TV With Stand (W x H x D)
1,232 x 755 x 286 mm / 48 5/8 x 29 3/4 x 11 3/8 inch
Dimension of Package Carton (W x H x D)
1,310 x 835 x 165 mm / 51.6 x 32.9 x 6.5 inch
Weight of TV Without Stand
16.3 kg / 35.9 lb
Weight of TV With Stand
16.8 kg / 37 lb
Weight of Package Carton (Gross)
22 kg / 48.5 lb

65” Model

General Features
Screen Size
65“
Brightness (cd/m²)
440
Contrast Ratio
5000:1
Dynamic Contrast Ratio
300,000:1
Response Time (ms)
9.5
Display Resolution (H x V, pixels)
3840 x 2160
HDR (High Dynamic Range) Compatibility
Yes (HDR10, HLG, Dolby Vision)
Aspect Ratio
16:9
Portrait/Tilt Compatibility
Yes

Display Features
Dimming Type
Frame Dimming
Display Device
LCD
Panel Type
VA
Backlight Type
Direct LED
TRILUMINOS Display
TRILUMINOS PRO
Color Gamut (DCI-P3)
92%
Picture Processor
4K HDR Processor X1
Operation Time
24/7
Deep Black Non-Glare Coating
No
Haze (%)
1%
Viewing Angle (Right/Left)
178(89/89) degrees
Viewing Angle (Up/Down)
178(89/89) degrees

Video Specs
Video Processing
4K X-Reality PRO
Motion Enhancer
Motionflow XR 240 (Native 60Hz)
HDMI Signal
4096 x 2160 p (24, 60 Hz), 3840 x 2160 p (24, 30, 60 Hz), 1080 p (24, 30, 60 Hz), 1080 i (60 Hz), 720 p (24, 30, 60 Hz), 480 p

Audio Specs
Speaker Position
Down Firing
Audio Power Output
10W + 10W

Professional Features
Pro Mode
Yes
HDMI Auto Wake-Up
Yes
HTML5 Platform
Yes
Multicast/IPTV
Yes
Operating System
Android TV
On-board Storage (GB)
16GB

Network Specs
Wi-Fi Direct
Yes
Wi-Fi Certified
Yes
Wireless LAN
Integrated

Convenience Features
USB Playback Codecs
MPEG1: MPEG1 / MPEG2PS: MPEG2 / MPEG2TS (HDV, AVCHD): MPEG2, AVC / MP4 (XAVCS): AVC, MPEG4, HEVC / AVI: Xvid, MotionJpeg / ASF (WMV): VC1 / MOV: AVC, MPEG4, MotionJpeg / MKV: Xvid, AVC, MPEG4, VP8.HEVC / WEBM: VP8 / 3GPP: MPEG4, AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG
On Screen Clock
Yes
Sleep Timer
Yes
On/Off Timer
Yes
Chromecast Built-in
Yes
Apple AirPlay
Yes

Control Specs
IP Control
Yes
RS-232C Control
Yes
HDMI-CEC
Yes

Inputs and Outputs
HDCP
HDCP2.3 (for HDMI 1/2/3/4)
Composite Video Input(s)
1 (Side, Mini jack)
HDMI Inputs Total
4 (4 Side)
Analog Audio Input(s) (Total)
1 (Side Analog Conversion)
Digital Audio Output(s)
1 (Side)
USB Ports
2 (Side)
Ethernet Inputs
1 (Side)

Design Features
VESA® Hole Pitch (W x H)
300 x 300 mm / 11.8 x 11.8 inch

Accessories
Wall-Mount Adjuster (Bundled)
*depending on the region.
Table-Top Stand (Optional)
*depending on the region.

Environment Specs
Rated Power Consumption
145 W
Power Consumption (in Standby)
0.5 W
Dynamic Backlight Control
Yes
Power Saving Mode / Back Light Off Mode
Yes

Measurements
Dimension of TV Without Stand (W x H x D)
1,449 x 831 x 70 mm / 57 x 32 5/8 x 2 7/8 inch
Dimension of TV With Stand (W x H x D)
1,449 x 892 x 286 mm / 57 x 35 1/8 x 11 3/8 inch
Dimension of Package Carton (W x H x D)
1,540 x 915 x 185 mm / 60.6 x 36 x 7.3 inch
Weight of TV Without Stand
21.1 kg / 46.5 lb
Weight of TV With Stand
21.5 kg / 47.4 lb
Weight of Package Carton (Gross)
30 kg / 66.1 lb

75” Model

General Features
Screen Size
75“
Brightness (cd/m²)
440
Contrast Ratio
5000:1
Dynamic Contrast Ratio
300,000:1
Response Time (ms)
9.5
Display Resolution (H x V, pixels)
3840 x 2160
HDR (High Dynamic Range) Compatibility
Yes (HDR10, HLG, Dolby Vision)
Aspect Ratio
16:9
Portrait/Tilt Compatibility
Yes

Display Features
Dimming Type
Frame Dimming
Display Device
LCD
Panel Type
VA
Backlight Type
Direct LED
TRILUMINOS Display
TRILUMINOS PRO
Color Gamut (DCI-P3)
92%
Picture Processor
4K HDR Processor X1
Operation Time
24/7
Deep Black Non-Glare Coating
No
Haze (%)
1%
Viewing Angle (Right/Left)
178(89/89) degrees
Viewing Angle (Up/Down)
178(89/89) degrees

Video Specs
Video Processing
4K X-Reality PRO
Motion Enhancer
Motionflow XR 240 (Native 60Hz)
HDMI Signal
4096 x 2160 p (24, 60 Hz), 3840 x 2160 p (24, 30, 60 Hz), 1080 p (24, 30, 60 Hz), 1080 i (60 Hz), 720 p (24, 30, 60 Hz), 480 p

Audio Specs
Speaker Position
Down Firing
Audio Power Output
10W + 10W

Professional Features
Pro Mode
Yes
HDMI Auto Wake-Up
Yes
HTML5 Platform
Yes
Multicast/IPTV
Yes
Operating System
Android TV
On-board Storage (GB)
16GB

Network Specs
Wi-Fi Direct
Yes
Wi-Fi Certified
Yes
Wireless LAN
Integrated

Convenience Features
USB Playback Codecs
MPEG1: MPEG1 / MPEG2PS: MPEG2 / MPEG2TS (HDV, AVCHD): MPEG2, AVC / MP4 (XAVCS): AVC, MPEG4, HEVC / AVI: Xvid, MotionJpeg / ASF (WMV): VC1 / MOV: AVC, MPEG4, MotionJpeg / MKV: Xvid, AVC, MPEG4, VP8.HEVC / WEBM: VP8 / 3GPP: MPEG4, AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG
On Screen Clock
Yes
Sleep Timer
Yes
On/Off Timer
Yes
Chromecast Built-in
Yes
Apple AirPlay
Yes

Control Specs
IP Control
Yes
RS-232C Control
Yes
HDMI-CEC
Yes

Inputs and Outputs
HDCP
HDCP2.3 (for HDMI 1/2/3/4)
Composite Video Input(s)
1 (Side, Mini jack)
HDMI Inputs Total
4 (4 Side)
Analog Audio Input(s) (Total)
1 (Side Analog Conversion)
Digital Audio Output(s)
1 (Side)
USB Ports
2 (Side)
Ethernet Inputs
1 (Side)

Design Features
VESA® Hole Pitch (W x H)
400 x 400 mm / 15.8 x 15.8 inch

Accessories
Wall-Mount Adjuster (Bundled)
*depending on the region.
Table-Top Stand (Optional)
*depending on the region.

Environment Specs
Rated Power Consumption
200 W
Power Consumption (in Standby)
0.5 W
Dynamic Backlight Control
Yes
Power Saving Mode / Back Light Off Mode
Yes

Measurements
Dimension of TV Without Stand (W x H x D)
1,677 x 965 x 70 mm / 66 x 38 x 2 7/8 inch
Dimension of TV With Stand (W x H x D)
1,677 x 1,029 x 286 mm / 66 x 40 5/8 x 11 3/8 inch
Dimension of Package Carton (W x H x D)
1,790 x 1,060 x 220 mm / 70.5 x 41.7 x 8.7 inch
Weight of TV Without Stand
31.3 kg / 69 lb
Weight of TV With Stand
31.8 kg / 70.1 lb
Weight of Package Carton (Gross)
42 kg / 92.6 lb

85” Model

General Features
Screen Size
85“
Brightness (cd/m²)
440
Contrast Ratio
5000:1
Dynamic Contrast Ratio
300,000:1
Response Time (ms)
9.5
Display Resolution (H x V, pixels)
3840 x 2160
HDR (High Dynamic Range) Compatibility
Yes (HDR10, HLG, Dolby Vision)
Aspect Ratio
16:9
Portrait/Tilt Compatibility
Yes

Display Features
Dimming Type
Frame Dimming
Display Device
LCD
Panel Type
VA
Backlight Type
Direct LED
TRILUMINOS Display
TRILUMINOS PRO
Color Gamut (DCI-P3)
92%
Picture Processor
4K HDR Processor X1
Operation Time
24/7
Deep Black Non-Glare Coating
No
Haze (%)
1%
Viewing Angle (Right/Left)
178(89/89) degrees
Viewing Angle (Up/Down)
178(89/89) degrees

Video Specs
Video Processing
4K X-Reality PRO
Motion Enhancer
Motionflow XR 240 (Native 60Hz)
HDMI Signal
4096 x 2160 p (24, 60 Hz), 3840 x 2160 p (24, 30, 60 Hz), 1080 p (24, 30, 60 Hz), 1080 i (60 Hz), 720 p (24, 30, 60 Hz), 480 p

Audio Specs
Speaker Position
Down Firing
Audio Power Output
10W + 10W

Professional Features
Pro Mode
Yes
HDMI Auto Wake-Up
Yes
HTML5 Platform
Yes
Multicast/IPTV
Yes
Operating System
Android TV
On-board Storage (GB)
16GB

Network Specs
Wi-Fi Direct
Yes
Wi-Fi Certified
Yes
Wireless LAN
Integrated

Convenience Features
USB Playback Codecs
MPEG1: MPEG1 / MPEG2PS: MPEG2 / MPEG2TS (HDV, AVCHD): MPEG2, AVC / MP4 (XAVCS): AVC, MPEG4, HEVC / AVI: Xvid, MotionJpeg / ASF (WMV): VC1 / MOV: AVC, MPEG4, MotionJpeg / MKV: Xvid, AVC, MPEG4, VP8.HEVC / WEBM: VP8 / 3GPP: MPEG4, AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG
On Screen Clock
Yes
Sleep Timer
Yes
On/Off Timer
Yes
Chromecast Built-in
Yes
Apple AirPlay
Yes

Control Specs
IP Control
Yes
RS-232C Control
Yes
HDMI-CEC
Yes

Inputs and Outputs
HDCP
HDCP2.3 (for HDMI 1/2/3/4)
Composite Video Input(s)
1 (Side, Mini jack)
HDMI Inputs Total
4 (4 Side)
Analog Audio Input(s) (Total)
1 (Side Analog Conversion)
Digital Audio Output(s)
1 (Side)
USB Ports
2 (Side)
Ethernet Inputs
1 (Side)

Design Features
VESA® Hole Pitch (W x H)
400 x 400 mm / 15.8 x 15.8 inch

Accessories
Wall-Mount Adjuster (Bundled)
*depending on the region.
Table-Top Stand (Optional)
*depending on the region.

Environment Specs
Rated Power Consumption
225 W
Power Consumption (in Standby)
0.5 W
Dynamic Backlight Control
Yes
Power Saving Mode / Back Light Off Mode
Yes

Measurements
Dimension of TV Without Stand (W x H x D)
1,915 x 1,105 x 70 mm / 75.4 x 43.5 x 2 7/8 inch
Dimension of TV With Stand (W x H x D)
1,915 x 1,158 x 286 mm / 75.4 x 45.6 x 11 3/8 inch
Dimension of Package Carton (W x H x D)
2,030 x 1,220 x 240 mm / 79.9 x 48 x 9.4 inch
Weight of TV Without Stand
42.4 kg / 93.5 lb
Weight of TV With Stand
43 kg / 94.8 lb
Weight of Package Carton (Gross)
59 kg / 130.1 lb

98” Model

General Features
Screen Size
98“
Brightness (cd/m²)
440
Contrast Ratio
5000:1
Dynamic Contrast Ratio
300,000:1
Response Time (ms)
9.5
Display Resolution (H x V, pixels)
3840 x 2160
HDR (High Dynamic Range) Compatibility
Yes (HDR10, HLG, Dolby Vision)
Aspect Ratio
16:9
Portrait/Tilt Compatibility
Yes

Display Features
Dimming Type
Frame Dimming
Display Device
LCD
Panel Type
VA
Backlight Type
Direct LED
TRILUMINOS Display
TRILUMINOS PRO
Color Gamut (DCI-P3)
92%
Picture Processor
4K HDR Processor X1
Operation Time
24/7
Deep Black Non-Glare Coating
No
Haze (%)
1%
Viewing Angle (Right/Left)
178(89/89) degrees
Viewing Angle (Up/Down)
178(89/89) degrees

Video Specs
Video Processing
4K X-Reality PRO
Motion Enhancer
Motionflow XR 240 (Native 60Hz)
HDMI Signal
4096 x 2160 p (24, 60 Hz), 3840 x 2160 p (24, 30, 60 Hz), 1080 p (24, 30, 60 Hz), 1080 i (60 Hz), 720 p (24, 30, 60 Hz), 480 p

Audio Specs
Speaker Position
Down Firing
Audio Power Output
20W + 20W

Professional Features
Pro Mode
Yes
HDMI Auto Wake-Up
Yes
HTML5 Platform
Yes
Multicast/IPTV
Yes
Operating System
Android TV
On-board Storage (GB)
16GB

Network Specs
Wi-Fi Direct
Yes
Wi-Fi Certified
Yes
Wireless LAN
Integrated

Convenience Features
USB Playback Codecs
MPEG1: MPEG1 / MPEG2PS: MPEG2 / MPEG2TS (HDV, AVCHD): MPEG2, AVC / MP4 (XAVCS): AVC, MPEG4, HEVC / AVI: Xvid, MotionJpeg / ASF (WMV): VC1 / MOV: AVC, MPEG4, MotionJpeg / MKV: Xvid, AVC, MPEG4, VP8.HEVC / WEBM: VP8 / 3GPP: MPEG4, AVC / MP3 / ASF (WMA) / LPCM / WAV / MP4AAC / FLAC / JPEG
On Screen Clock
Yes
Sleep Timer
Yes
On/Off Timer
Yes
Chromecast Built-in
Yes
Apple AirPlay
Yes

Control Specs
IP Control
Yes
RS-232C Control
Yes
HDMI-CEC
Yes

Inputs and Outputs
HDCP
HDCP2.3 (for HDMI 1/2/3/4)
Composite Video Input(s)
1 (Side, Mini jack)
HDMI Inputs Total
4 (4 Side)
Analog Audio Input(s) (Total)
1 (Side Analog Conversion)
Digital Audio Output(s)
1 (Side)
USB Ports
2 (Side)
Ethernet Inputs
1 (Side)

Design Features
VESA® Hole Pitch (W x H)
600 x 400 mm / 23.6 x 15.8 inch

Accessories
Wall-Mount Adjuster (Bundled)
*depending on the region.
Table-Top Stand (Optional)
*depending on the region.

Environment Specs
Rated Power Consumption
400 W
Power Consumption (in Standby)
0.5 W
Dynamic Backlight Control
Yes
Power Saving Mode / Back Light Off Mode
Yes

Measurements
Dimension of TV Without Stand (W x H x D)
2,187 x 1,272 x 90 mm / 86.3 x 50.1 x 3.5 inch
Dimension of TV With Stand (W x H x D)
2,187 x 1,328 x 335 mm / 86.3 x 52.4 x 13.2 inch
Dimension of Package Carton (W x H x D)
2,380 x 1,430 x 270 mm / 93.7 x 56.3 x 10.6 inch
Weight of TV Without Stand
74.3 kg / 163.1 lb
Weight of TV With Stand
76.5 kg / 168.7 lb
Weight of Package Carton (Gross)
106 kg / 233.7 lb
